Overview
In its simplest form, the M33 BluOS™ enabled DAC/amplifier is an ultra-high-performance streaming amplifier with superb audiophile sound. As a BluOS enabled component, the M33 can be combined with other players in a BluOS ecosystem of wirelessly networked music players throughout the home for an outstanding whole-home audio system. With the employment of the new Purifi Eigentakt™ Hybrid Digital amplifier technology, the M33 follows NAD’s long-standing tradition in identifying and developing cutting-edge amplification technology. With a minimum of 200W per channel on tap, the result is lifelike performance, exemplified by ultra-low distortion and noise.
Features
- BluOS Streaming DAC Amplifier
- HybridDigital Purifi Eigentakt™ Amplifier Technology
- Continuous Power: 200W into 8/4 Ohms
- 32-BIT/384kHz ESS Sabre DAC
- Dirac Live Room LE Correction*
- Colour LCD touch display
- BluOS multi-room Integration
- 2 x MDC Slots for Future Expansion
- Wireless control with AirPlay 2 and aptX HD Bluetooth Integration
- Comprehensive digital and analog connectivity including HDMI eARC
- Integrates seamlessly with leading smarthome control systems
- MDC (Modular Design Construction) offers ability to upgrade to future digital formats as they become available. Two MDC slots provided.
- CI friendly- RS232 Serial Control Port. Trigger In/Out.
- IR In with learning function
*Full Dirac Live and Bass Control upgrades can be purchased through the Dirac Live software.
Specifications
| Rated output power (ref. 20 Hz-20 kHz at rated THD, both channels driven) |
>200 W into 8 ohms >380 W into 4 ohms |
| Rated output power, Bridge mode (ref. 20 Hz – 20 kHz at rated THD) |
>700 W into 8 ohms |
| Input sensitivity |
865 mV (ref. 200W 8 ohms, Volume maximum) |
| THD (20 Hz – 20 kHz) |
<0.003 % (1W to 200 W, 8 ohms and 4 ohms) |
| Signal-to-Noise ratio |
>98 dB (A-weighted, ref. 1 W out in 8 ohms) >120 dB (A-weighted, ref. 200 W out in 8 ohms) |
| Clipping power |
>210 W (0.1 % THD 1 kHz 8 ohms) |
|
IHF dynamic power |
8 ohms: 260 W 4 ohms: 520 W |
|
Peak output current |
≥25 A (in 1 ohm, 1 ms) |
|
Damping factor |
>800 (ref. 8 ohms, 20 Hz to 6.5 kHz) |
|
Frequency response |
±0.2 dB (20 Hz -20 kHz) -3 dB at 60 kHz |
|
Input Impedance (r and c) |
47kΩ/180pF |
| Input Sensitivity | 280mV (ref. 500mV out, Volume Maximum) |
| Maximum input level 20Hz-20Khz | 2 Vrms/8 Vrms (low sensitivity mode) |
| Tone Controls |
Treble: ±10dB at 10kHz Bass: ±10dB at 100Hz |
| Max Output Signal | 4Vrms (ref. 0.1% THD) |
| PREOUT Maximum output level | 3.9 Vrms (ref. 0.1% THD) |
| PREOUT Signal-to-Noise ratio | >120 dB (A-weighted, ref. 2 V out) |
| PREOUT Output impedance | 100 ohms |
| SUBOUT Maximum output level | 1.1 Vrms (ref. 0.1 % THD 100Hz) |
| SUBOUT Signal-to-Noise ratio | >102 dB (20 Hz-20 kHz, ref. 1V out) |
| SUBOUT THD+N | <0.005 % (refer 1.1 V 20 Hz-200 Hz) |
| SUBOUT Output impedance | 680 ohms |
| PHONO Input sensitivity |
MM: 1.2 mV
|
|
PHONO Input impedance (R and C) |
MM: 56 kohms/100 pF MC: 100 ohms/280 pF |
|
PHONO Signal to noise ratio (ref. 2 V Preout A-weighted) |
MM: >92 dB MC: >76 dB |
|
PHONO THD+N (ref 2V Preout 1kHz) |
MM: <0.003 % MC: <0.02 % |
|
RIAA response accuracy MM/MC |
±0.2 dB 20 Hz -20 kHz |
|
HEADPHONES Output Impedance |
2.2ohms |
|
HEADPHONES Output Power |
>100 mW/32 ohms |
|
Supported audio file format* |
MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS |
| Supported high- resolution audio file format* | FLAC, MQA, WAV, AIFF |
| Sampling rate | up to 192 kHz |
| Bit depths | 16 – 24 |
| Network connectivity | Gigabit Ethernet RJ45, Wi-Fi 5 |
| Supported network file share protocol | Server Message Block (SMB) |
| USB | 1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals |
| Bluetooth quality | aptX HD 5.0 |
| Bluetooth connectivity | Two-Way (Receive and Headphone modes) |
| Supported operating system | Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions |
| Mobile Application | Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops |
| Front panel | 7-inch full colour touch screen |
| Remote control | HTRM 2 remote control |
| Power Consumption |
Auto Standby ON <0.5W Idle Power <40W |
| Dimensions WxHxD ** | 435 x 133 x 396 mm (17 1/8 x 5 1/4 x 15 5/8”) |
| Net Weight | 9.7kg (21.4lb) |
| Shipping Weight | 18.4kg (40.6 lb) |
* – Supported audio file format, cloud services and free internet radio are subject to change without notice.
** – Gross dimension includes feet and extended rear panel terminals
